Capacity: 1200～1500 Pcs / h
This machine is designed for fast product changeovers and supports labeling for 6+6, 10, 12, and 18-egg cartons. Format switching is achieved by adjusting the labeling system, mold conveyor, and suction feeding unit. The maximum compatible egg carton length is 304 mm.
| Project | Details |
|---|---|
| Equipment Name and Model | TB40C Glue Applying and Labeling Machine |
| Dimensions | Approx. 8500 mm × 1970 mm × 1820 mm |
| System Components | Automatic feeding and separating system, automatic egg carton conveying system, automatic egg carton labeling system, internal printing module, internal labeling module, automatic stacking system, and automatic electrical control system |
| Modular Design | The internal printing and labeling modules adopt a modular design, allowing quick assembly and switching between functions. |
| Applicable Product Types | 6+6, 10, 12, and 18-egg cartons (requires replacement of the corresponding devices) |
| Maximum Egg Carton Size | Length ≤ 304 mm |
| Labeling Method | Glue application method |
| Label Dispensing Accuracy | ±1 mm |
| Labeling Accuracy | ±3 mm |
| Applicable Label Size | Length ≤ 285 mm, Width ≤ 213 mm |
| Capacity | 1,200–1,500 pieces/hour |
| Product Changeover | Product switching can be achieved by replacing the labeling device, contour mold conveying device, and suction cup feeding mechanism. |
